Zero Trust Access in the Cloud: How the Evaluation Loop Actually Works

by
Reading Time: 10 minutes

Meta Description: Understand how zero trust access in the cloud works end to end — continuous verification, least privilege enforcement, and the full policy evaluation loop.

What Is Cloud IAM → Authentication vs Authorization → IAM Roles vs Policies → AWS IAM Deep Dive → GCP Resource Hierarchy IAM → Azure RBAC Scopes → OIDC Workload Identity → AWS IAM Privilege Escalation → AWS Least Privilege Audit → SAML vs OIDC Federation → Kubernetes RBAC and AWS IAM → Zero Trust Access in the Cloud

TL;DR

  • Zero Trust: trust nothing implicitly, verify everything explicitly, minimize blast radius by assuming you will be breached
  • Network location is not identity — VPN is authentication for the tunnel, not authorization for the resource
  • JIT privilege elevation removes standing admin access: engineers request elevation for a specific purpose, scoped to a specific duration
  • Device posture is an access signal — a compromised endpoint with valid credentials is still a threat; Conditional Access gates on device compliance
  • Continuous session validation re-evaluates signals throughout the session — device falls out of compliance, sessions revoke in minutes, not at expiry
  • The highest-ROI early moves: eliminate machine static credentials, enforce MFA on all human access, federate to a single IdP

The Big Picture

  ZERO TRUST IAM — EVERY REQUEST EVALUATED INDEPENDENTLY

  API call arrives
         │
         ▼
  Identity verified? ──── No ────► DENY
         │
        Yes
         │
         ▼
  Device compliant? ───── No ────► DENY (or step-up MFA)
         │
        Yes
         │
         ▼
  Policy allows this  ─── No ────► DENY
  action on this ARN?
         │
        Yes
         │
         ▼
  Conditions met? ─────── No ────► DENY
  (time, IP, MFA age,              (e.g., outside business hours,
   risk score, session)             impossible travel detected)
         │
        Yes
         │
         ▼
       ALLOW ──────────────────────► LOG every decision (allow and deny)
         │
         └── Continuous re-evaluation:
             device state changes → revoke
             anomaly detected → revoke or step-up
             credential age → require re-auth

Introduction

The perimeter model of network security made a bet: inside the network is trusted, outside is not. Lock down the perimeter tightly enough and you’re safe. VPN in, and you’re one of us.

I grew up professionally in that model. Firewalls, DMZs, trusted zones. The idea had intuitive appeal — you build walls, you control what crosses them. For a while it worked reasonably well.

Then I watched it fail, repeatedly, in ways that were predictable in hindsight. An engineer’s laptop gets compromised at a coffee shop. They VPN in. Now the attacker is “inside.” A contractor account gets phished. They have valid Active Directory credentials. They’re inside. A cloud service gets misconfigured and exposes a management interface. There’s no perimeter for that to be inside of.

The perimeter model failed not because the walls weren’t strong enough, but because the premise was wrong. There is no inside. There is no perimeter that reliably separates trusted from untrusted. In a world of remote work, cloud services, contractor access, and API integrations, the attack surface doesn’t respect network boundaries.

Zero Trust is the architecture built on a different premise: trust nothing implicitly. Verify everything explicitly. Minimize blast radius by assuming you will be breached.

This isn’t a product you buy. It’s a set of principles applied to how you design, build, and operate your IAM. This episode is how those principles translate to concrete practices — building on everything we’ve covered in this series.

The Three Principles

Verify Explicitly

Every request must carry verifiable identity and context. Network location is not identity.

Old model: request from 10.0.0.0/8 → trusted, proceed
Zero Trust: request from 10.0.0.0/8 → still must present verifiable identity
                                       still must pass authorization check
                                       still must pass context evaluation
                                       then proceed (or deny)

In cloud IAM terms: every API call carries identity claims (IAM role ARN, federated identity, managed identity), and those claims are verified against policy on every single request. There’s no concept of “once authenticated, trusted until logout.” In cloud IAM, this already exists natively. Every API call is authenticated and authorized independently. The challenge is extending this model to internal services, internal APIs, and human access patterns.

Implementation in practice:
– mTLS for service-to-service communication — both sides present certificates; identity is the certificate, not the network path
– Bearer tokens on every internal API call — no session cookies, no “we’re on the same VPC so it’s fine”
– Short-lived credentials everywhere — a compromised credential expires, not “after the session times out in 8 hours”

Use Least Privilege — Just-in-Time, Just-Enough

No standing access to sensitive resources. Access granted when needed, for the minimum scope, for the minimum duration.

Old model: alice is in the DBA group → permanent access to all databases
Zero Trust: alice requests access to production DB →
            verified: alice's device is enrolled in MDM and compliant
            verified: alice has an open change ticket for this task
            verified: current time is within business hours
            granted: connection to this specific database, from alice's specific IP
                     for 2 hours, then revoked automatically

This is JIT access. It reduces the window where a compromised credential can cause damage. It requires a change in how engineers think about access: access is not a property you have, it’s something you request when you need it. The operational friction is a feature, not a bug. Justifying each elevated access request is what keeps the access model honest.

Assume Breach

Design systems as if the attacker is already inside. This drives different decisions:

  • Micro-segmentation: one role per service, minimum permissions per role. If one service is compromised, it can’t pivot to everything else.
  • Log everything: every authorization decision, allow or deny. When you’re investigating an incident, you need to know what happened, not just that something happened.
  • Automate response: anomalous API call pattern → trigger automated credential revocation or session termination. Don’t wait for a human to notice.

Building Zero Trust IAM — Block by Block

Block 1: Strong Identity Foundation

You can’t verify explicitly without strong authentication. The starting point:

# AWS: require MFA for all IAM operations — enforce via SCP across the org
{
  "Effect": "Deny",
  "Action": "*",
  "Resource": "*",
  "Condition": {
    "BoolIfExists": {
      "aws:MultiFactorAuthPresent": "false"
    },
    "StringNotLike": {
      "aws:PrincipalArn": [
        "arn:aws:iam::*:role/AWSServiceRole*",
        "arn:aws:iam::*:role/OrganizationAccountAccessRole"
      ]
    }
  }
}

# GCP: enforce OS Login for VM SSH (ties SSH access to Google identity, not SSH keys)
gcloud compute project-info add-metadata \
  --metadata enable-oslogin=TRUE

# This means: SSH to a VM requires your Google identity to have roles/compute.osLogin
# or roles/compute.osAdminLogin. No more managing ~/.authorized_keys files on instances.

For human access: hardware FIDO2 keys (YubiKey, Google Titan) rather than TOTP where possible. TOTP codes can be phished in real-time adversary-in-the-middle attacks. Hardware keys cannot — the cryptographic challenge-response is bound to the origin URL.

Block 2: Device Posture as an Access Signal

In a Zero Trust model, the identity of the user is necessary but not sufficient. The state of the device matters too — a compromised endpoint with valid credentials is still a threat.

# Azure Conditional Access: block access from non-compliant devices
# (configures in Entra ID Conditional Access portal)
conditions:
  clientAppTypes: [browser, mobileAppsAndDesktopClients]
  devices:
    deviceFilter:
      mode: exclude
      rule: "device.isCompliant -eq True and device.trustType -eq 'AzureAD'"
grantControls:
  builtInControls: [compliantDevice]

# AWS Verified Access: identity + device posture for application access — no VPN
aws ec2 create-verified-access-instance \
  --description "Zero Trust app access"

# Attach identity trust provider (Okta OIDC)
aws ec2 create-verified-access-trust-provider \
  --trust-provider-type user \
  --user-trust-provider-type oidc \
  --oidc-options IssuerURL=https://company.okta.com,ClientId=...,ClientSecret=...,Scope=openid

# Attach device trust provider (Jamf, Intune, or CrowdStrike)
aws ec2 create-verified-access-trust-provider \
  --trust-provider-type device \
  --device-trust-provider-type jamf \
  --device-options TenantId=JAMF_TENANT_ID

AWS Verified Access allows users to reach internal applications by verifying both their identity (via OIDC) and their device health (via MDM) — without a VPN. The access gateway evaluates both signals on every connection, not just at login.

Block 3: Just-in-Time Privilege Elevation

No standing elevated access. Engineers are eligible for elevated roles; they activate them when needed.

# Azure PIM: engineer activates an eligible privileged role
az rest --method POST \
  --uri "https://graph.microsoft.com/v1.0/roleManagement/directory/roleAssignmentScheduleRequests" \
  --body '{
    "action": "selfActivate",
    "principalId": "USER_OBJECT_ID",
    "roleDefinitionId": "ROLE_DEF_ID",
    "directoryScopeId": "/",
    "justification": "Investigating security alert in tenant — incident ticket INC-2026-0411",
    "scheduleInfo": {
      "startDateTime": "2026-04-11T09:00:00Z",
      "expiration": {"type": "AfterDuration", "duration": "PT4H"}
    }
  }'
# Access activates, lasts 4 hours, then automatically removed

# AWS: temporary account assignment via Identity Center
# (typically triggered by ITSM workflow integration, not manual CLI)
aws sso-admin create-account-assignment \
  --instance-arn "arn:aws:sso:::instance/ssoins-xxx" \
  --target-id ACCOUNT_ID \
  --target-type AWS_ACCOUNT \
  --permission-set-arn "arn:aws:sso:::permissionSet/ssoins-xxx/ps-yyy" \
  --principal-type USER \
  --principal-id USER_ID

# Schedule deletion (using EventBridge + Lambda in a real deployment)
aws sso-admin delete-account-assignment \
  --instance-arn "arn:aws:sso:::instance/ssoins-xxx" \
  --target-id ACCOUNT_ID \
  --target-type AWS_ACCOUNT \
  --permission-set-arn "arn:aws:sso:::permissionSet/ssoins-xxx/ps-yyy" \
  --principal-type USER \
  --principal-id USER_ID

The operational change this requires: engineers stop thinking of access as something they hold permanently and start thinking of it as something they request for a specific purpose.

This feels like friction until you’re investigating an incident and you have a precise record of who activated what elevated access and why.

Block 4: Continuous Session Validation

Traditional auth: verify once at login, trust the session until timeout.
Zero Trust auth: re-evaluate access signals continuously throughout the session.

Session starts: identity verified + device compliant + IP in expected range
                → access granted

15 minutes later: impossible travel detected (IP changes to different country)
                  → step-up authentication required, or session terminated

Later: device compliance state changes (EDR detects malware)
       → all active sessions for this device revoked immediately

This requires integration between your identity platform and your device management / EDR tooling. Entra ID Conditional Access with Continuous Access Evaluation (CAE) implements this natively. When certain events occur — device compliance change, IP anomaly, token revocation — access tokens are invalidated within minutes rather than waiting for natural expiry.

// GCP: bind IAM access to an Access Context Manager access level
// Access level enforces device compliance — if device falls out of compliance,
// the access level is no longer satisfied and requests fail immediately
gcloud projects add-iam-policy-binding my-project \
  --member="user:[email protected]" \
  --role="roles/bigquery.admin" \
  --condition="expression=request.auth.access_levels.exists(x, x == 'accessPolicies/POLICY_NUM/accessLevels/corporate_compliant_device'),title=Compliant device required"

Block 5: Micro-Segmented Permissions

Every service has its own identity. Every identity has only what it needs. Compromise of one service cannot propagate to others.

# Terraform: IAM as code — each service gets a dedicated, scoped role
resource "aws_iam_role" "order_processor" {
  name                 = "svc-order-processor"
  permissions_boundary = aws_iam_policy.service_boundary.arn

  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect    = "Allow"
      Principal = { Service = "lambda.amazonaws.com" }
      Action    = "sts:AssumeRole"
    }]
  })
}

resource "aws_iam_role_policy" "order_processor" {
  name   = "order-processor-policy"
  role   = aws_iam_role.order_processor.id
  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect   = "Allow"
        Action   = ["sqs:ReceiveMessage", "sqs:DeleteMessage", "sqs:GetQueueAttributes"]
        Resource = aws_sqs_queue.orders.arn
      },
      {
        Effect   = "Allow"
        Action   = ["dynamodb:PutItem", "dynamodb:GetItem", "dynamodb:UpdateItem"]
        Resource = aws_dynamodb_table.orders.arn
      }
    ]
  })
}

# Open Policy Agent: enforce IAM standards at the policy level
# Run this in CI/CD — fail the build if any policy statement has wildcard actions
package iam.policy

deny[msg] {
  input.Statement[i].Effect == "Allow"
  input.Statement[i].Action == "*"
  msg := sprintf("Statement %d has wildcard Action — not allowed", [i])
}

deny[msg] {
  input.Statement[i].Effect == "Allow"
  input.Statement[i].Resource == "*"
  endswith(input.Statement[i].Action, "Delete")
  msg := sprintf("Statement %d allows Delete on all resources — requires specific ARN", [i])
}

Block 6: Universal Audit Trail

Zero Trust without logging is just obscurity. Every authorization decision — allow and deny — must be logged, retained, and queryable.

# AWS: verify CloudTrail is comprehensive
aws cloudtrail get-trail-status --name management-trail
# Must have: LoggingEnabled=true, IsMultiRegionTrail=true, IncludeGlobalServiceEvents=true

# Verify no management events are excluded
aws cloudtrail get-event-selectors --trail-name management-trail \
  | jq '.EventSelectors[] | {ReadWrite: .ReadWriteType, Mgmt: .IncludeManagementEvents}'
# ReadWriteType should be "All"; IncludeManagementEvents should be true

# GCP: ensure Data Access audit logs are enabled for IAM
gcloud projects get-iam-policy my-project --format=json | jq '.auditConfigs'
# Should see auditLogConfigs for cloudresourcemanager.googleapis.com and iam.googleapis.com
# with both DATA_READ and DATA_WRITE enabled

# Azure: route Entra ID logs to Log Analytics for long-term retention and querying
az monitor diagnostic-settings create \
  --name entra-audit-to-la \
  --resource "/tenants/TENANT_ID/providers/microsoft.aad/domains/company.com" \
  --logs '[{"category":"AuditLogs","enabled":true},{"category":"SignInLogs","enabled":true}]' \
  --workspace /subscriptions/SUB_ID/resourceGroups/rg-monitoring/providers/Microsoft.OperationalInsights/workspaces/security-logs

Framework Alignment

Zero Trust IAM isn’t a framework itself — it’s a design philosophy. But it maps cleanly onto the controls that compliance frameworks are pushing organizations toward:

Framework Reference What It Covers Here
CISSP Domain 5 — IAM Zero Trust reframes IAM as continuous, context-aware verification rather than perimeter-based trust
CISSP Domain 1 — Security & Risk Management Assume breach as a risk management posture; blast radius minimization through least privilege
CISSP Domain 7 — Security Operations Continuous monitoring, anomaly detection, and automated response are operational requirements of Zero Trust
ISO 27001:2022 5.15 Access control Zero Trust access policy: verify explicitly, least privilege, assume breach
ISO 27001:2022 8.16 Monitoring activities Continuous session validation and universal audit trail — all authorization decisions logged
ISO 27001:2022 8.20 Networks security Micro-segmentation and mTLS replace implicit network trust with verified identity at every hop
ISO 27001:2022 5.23 Information security for cloud services Zero Trust architecture applied to cloud IAM across AWS, GCP, and Azure
SOC 2 CC6.1 Zero Trust logical access controls — JIT, device posture, context-aware authorization
SOC 2 CC6.7 Continuous session validation and transmission controls across all system components
SOC 2 CC7.1 Threat detection through universal audit trails and anomaly-triggered automated response
SOC 2 CC7.2 Incident response — automated revocation and session termination on anomaly detection

Zero Trust Maturity — Where to Start

In practice, most organizations think about Zero Trust as a destination — a large, multi-year program. The reality is it’s a direction. Any movement in that direction reduces risk.

Level Where You Are What to Build Next
1 — Initial Some MFA; static credentials for machines; no centralized IdP Eliminate machine static keys → workload identity
2 — Managed Centralized IdP; SSO for most systems; some MFA enforcement Close SSO gaps; enforce MFA everywhere; federate to cloud
3 — Defined Least privilege being enforced; audit tooling in use; JIT for some privileged access Expand JIT; policy-as-code in CI/CD; quarterly access reviews
4 — Contextual Device posture in access decisions; conditional access policies Continuous session evaluation; automated anomaly response
5 — Optimizing Policy-as-code everywhere; automated right-sizing; anomaly-triggered revocation Refine and maintain — Zero Trust is never “done”

The jump from Level 1 to Level 3 delivers the most security value per unit of effort. Start there. Don’t defer least privilege enforcement while you build a sophisticated device posture integration.

The Practical Sequence

If you’re building Zero Trust IAM from where most organizations are, this is the order that maximizes early security value:

  1. Inventory all identities — human and machine. You cannot secure what you can’t see. Build a complete picture before changing anything.

  2. Eliminate static credentials for machines — replace access keys and SA key files with workload identity. This is the highest-ROI change in most environments.

  3. Enforce MFA for all human access — especially cloud consoles, IdP admin, and VPN. Hardware keys for privileged accounts.

  4. Federate human identity — single IdP, SSO to cloud and major applications. Centralize the revocation path.

  5. Right-size IAM permissions — use last-accessed data and IAM Recommender to find and remove unused permissions. This is a continuous discipline, not a one-time clean-up.

  6. JIT for privileged access — Azure PIM, AWS Identity Center assignment automation, or equivalent for all elevated roles. No standing admin.

  7. IAM as code — all IAM changes via Terraform/Pulumi/CDK, reviewed in pull requests, validated by Access Analyzer or OPA in CI/CD, applied through automation.

  8. Continuous monitoring — alerts on IAM mutations, anomalous API call patterns, new cross-account trust relationships, new public resource exposures.

  9. Add context signals — Conditional Access policies incorporating device posture. Access Context Manager in GCP. AWS Verified Access for application access.

  10. Automated response — anomaly detected → automatic credential suspension or session termination. Close the window between detection and containment.

Series Complete

This series covered Cloud IAM from the question “what even is IAM?” to Zero Trust architecture:

Episode Topic The Core Lesson
EP01 What is IAM? Access management is deny-by-default; every grant is an explicit decision
EP02 AuthN vs AuthZ Two separate gates; passing one doesn’t open the other
EP03 Roles, Policies, Permissions Structure prevents drift; wildcards accumulate into exposure
EP04 AWS IAM Deep Dive Trust policies and permission policies are both required; the evaluation chain has six layers
EP05 GCP IAM Deep Dive Hierarchy inheritance is a feature that needs careful handling; service account keys are an antipattern
EP06 Azure RBAC and Entra ID Two separate authorization planes; managed identities are the right model for workloads
EP07 Workload Identity Static credentials for machines are solvable at the root; OIDC token exchange replaces them
EP08 IAM Attack Paths The attack chain runs through IAM; iam:PassRole and its equivalents are privilege escalation primitives
EP09 Least Privilege Auditing 5% utilization is the average; the 95% excess is attack surface — and it’s measurable
EP10 Federation, OIDC, SAML The IdP is the trust anchor; everything downstream is bounded by its security
EP11 Kubernetes RBAC Two separate IAM layers; both must be secured; cluster-admin is the first thing to audit
EP12 Zero Trust IAM Trust nothing implicitly; verify everything explicitly; minimize blast radius through least privilege at every layer

IAM is not a feature you configure. It’s a practice you maintain. The organizations that operate with genuinely low cloud IAM risk don’t have fewer identities — they have better visibility into what those identities can do, and why, and what happened when something went wrong.

That’s what this series has been building toward.

The full series is at linuxcent.com/cloud-iam-series. If you found it useful, the best thing you can do is subscribe — the next series covers eBPF: what’s actually running in kernel space when Cilium, Falco, and Tetragon are doing their work.

Subscribe → linuxcent.com/subscribe

SAML vs OIDC: Which Federation Protocol Belongs in Your Cloud?

by
Reading Time: 10 minutes

Meta Description: Choose between SAML vs OIDC federation for your cloud — understand token formats, trust flows, and which protocol fits your IdP and workload mix.

What Is Cloud IAM → Authentication vs Authorization → IAM Roles vs Policies → AWS IAM Deep Dive → GCP Resource Hierarchy IAM → Azure RBAC Scopes → OIDC Workload Identity → AWS IAM Privilege Escalation → AWS Least Privilege Audit → SAML vs OIDC Federation

TL;DR

  • Federation means downstream systems trust the IdP’s signed assertion — they never see credentials and don’t manage them independently
  • SAML is XML-based, browser-oriented, the enterprise standard; OIDC is JWT-based, API-native, the modern protocol for workload identity and consumer SSO
  • In OIDC trust policies, the sub condition is the security boundary — omitting it means any GitHub Actions workflow in any repository can assume your role
  • Validate all JWT claims: signature, iss, aud, exp, sub — libraries do this, but need correct configuration (especially aud)
  • The IdP is the trust anchor: compromise the IdP and every downstream system is compromised. Treat IdP admin access with the same controls as your most sensitive system.
  • JIT provisioning and Conditional Access extend federation from “who are you” to “are you in an appropriate context right now”

The Big Picture

  FEDERATION: HOW TRUST FLOWS FROM IdP TO DOWNSTREAM SYSTEMS

  Identity Provider  (Okta / Entra ID / Google / AD FS)
  ┌──────────────────────────────────────────────────────────────────┐
  │  User or workload authenticates → IdP issues signed assertion   │
  │                                                                  │
  │  ┌──────────────────────────┐  ┌───────────────────────────┐   │
  │  │  SAML Assertion (XML)    │  │  OIDC ID Token (JWT)       │   │
  │  │  RSA-signed, 5–10 min    │  │  RS256-signed, ~1 hr      │   │
  │  │  Audience: SP entity ID  │  │  aud: client ID           │   │
  │  │  Subject: user identity  │  │  sub: specific workload   │   │
  │  └───────────┬──────────────┘  └──────────┬────────────────┘   │
  └─────────────────────────────────────────────────────────────────┘
                 │  human SSO                  │  workload identity
                 ▼                             ▼
  ┌─────────────────────────┐  ┌───────────────────────────────────┐
  │ SP validates signature  │  │ AWS STS / GCP STS validates       │
  │ + audience + timestamp  │  │ signature + iss + aud + sub       │
  │ → console session       │  │ → AssumeRoleWithWebIdentity       │
  └─────────────────────────┘  └───────────────────────────────────┘

  Security bound: IdP security bounds every system that trusts it
  Disable in Okta → access revoked everywhere that trusts Okta

Introduction

Before federation existed, every system had its own user database. Your Jira account. Your AWS account. Your Salesforce account. Your internal wiki. Each one had its own password, its own MFA, its own offboarding process. When an engineer joined, someone had to create accounts in every system. When they left, you hoped whoever processed the offboarding remembered to deactivate all of them.

I’ve done that audit — the one where you’re trying to figure out if a former employee still has access to anything. You go system by system, cross-reference against HR records, find accounts that exist in places you’ve forgotten the company even uses. In one environment I found an ex-engineer’s account still active in a vendor portal six months after they left, because that system was set up by someone who had since also left the company, and nobody had documented it.

Federation solves this structurally. One identity provider. One place to authenticate. One place to revoke. Every downstream system trusts the IdP’s assertion rather than managing credentials independently. Disable someone in Okta and they lose access everywhere that trusts Okta — immediately, without a checklist.

This episode is how federation actually works at the protocol level, because understanding the mechanism is what lets you design it securely. A federation setup with a trust policy that accepts assertions from any OIDC issuer is worse than no federation — it’s a false sense of security.

The Federation Model

Identity Provider (IdP)          Service Provider (SP) / Relying Party
  (Okta, Google, AD FS, Entra ID)       (AWS, Salesforce, GitHub, your app)
         │                                          │
         │  1. User authenticates to IdP             │
         │     (password + MFA)                      │
         │                                          │
         │  2. IdP generates a signed assertion      │
         │     (SAML response or OIDC ID Token)      │
         │ ──────────────────────────────────────── ▶│
         │                                          │
         │  3. SP validates the signature            │
         │     (using IdP's public certificate       │
         │      or JWKS endpoint)                    │
         │  4. SP maps identity to local permissions │
         │  5. SP grants access                      │

The SP never sees the user’s password. It never has one. It trusts the IdP’s cryptographic signature — if the assertion is signed with the IdP’s private key, and the SP trusts that key, the identity is accepted.

This trust chain has one critical property: the security of every SP is bounded by the security of the IdP. Compromise the IdP, and every system that trusts it is compromised. This is why IdP security deserves the same attention as the most sensitive system it gates access to.

SAML 2.0 — The Enterprise Standard

SAML (Security Assertion Markup Language) is XML-based, verbose, and battle-tested. Published in 2005, it’s the protocol behind most enterprise SSO deployments. When your company says “use your corporate login for this vendor app,” SAML is usually the mechanism.

How a SAML Login Flows

1. User visits AWS console (the Service Provider)
2. AWS checks: no active session → redirect to IdP
   → https://company.okta.com/saml?SAMLRequest=...
3. Okta authenticates the user (password, MFA)
4. Okta generates a SAML Assertion — a signed XML document containing:
   - Who the user is (Subject, typically email)
   - Their attributes (group memberships, custom attributes)
   - When the assertion was issued and when it expires (valid 5-10 minutes typically)
   - Which SP this is for (Audience restriction)
   - Okta's digital signature (RSA-SHA256 or similar)
5. Browser POSTs the assertion to AWS's ACS (Assertion Consumer Service) URL
6. AWS validates the signature against Okta's public cert (retrieved from Okta's metadata URL)
7. AWS reads the SAML attribute for the IAM role
8. AWS calls sts:AssumeRoleWithSAML → issues temporary credentials
9. User gets a console session — no AWS credentials were ever stored anywhere

What a SAML Assertion Actually Looks Like

<saml:Assertion>
  <saml:Issuer>https://okta.company.com</saml:Issuer>

  <saml:Subject>
    <saml:NameID>[email protected]</saml:NameID>
  </saml:Subject>

  <saml:AttributeStatement>
    <!-- This attribute tells AWS which IAM role to assume -->
    <saml:Attribute Name="https://aws.amazon.com/SAML/Attributes/Role">
      <saml:AttributeValue>
        arn:aws:iam::123456789012:role/EngineerRole,arn:aws:iam::123456789012:saml-provider/OktaProvider
      </saml:AttributeValue>
    </saml:Attribute>
  </saml:AttributeStatement>

  <!-- Critical: time bounds on this assertion -->
  <saml:Conditions NotBefore="2026-04-11T09:00:00Z" NotOnOrAfter="2026-04-11T09:05:00Z">
    <saml:AudienceRestriction>
      <!-- Critical: this assertion is ONLY valid for AWS -->
      <saml:Audience>https://signin.aws.amazon.com/saml</saml:Audience>
    </saml:AudienceRestriction>
  </saml:Conditions>

  <ds:Signature>... RSA-SHA256 signature over the above ...</ds:Signature>
</saml:Assertion>

The Audience restriction and the NotOnOrAfter timestamp are two of the most security-critical fields. The audience ensures this assertion can’t be reused for a different SP. The timestamp ensures it can’t be replayed after expiry.

Setting Up SAML Federation with AWS

# Register Okta as a SAML provider in AWS IAM
aws iam create-saml-provider \
  --saml-metadata-document file://okta-metadata.xml \
  --name OktaProvider

# Create the IAM role that federated users will assume
aws iam create-role \
  --role-name EngineerRole \
  --assume-role-policy-document '{
    "Version": "2012-10-17",
    "Statement": [{
      "Effect": "Allow",
      "Principal": {
        "Federated": "arn:aws:iam::123456789012:saml-provider/OktaProvider"
      },
      "Action": "sts:AssumeRoleWithSAML",
      "Condition": {
        "StringEquals": {
          "SAML:aud": "https://signin.aws.amazon.com/saml"
        }
      }
    }]
  }'

# In Okta: configure the AWS IAM Identity Center app
# Attribute mapping: https://aws.amazon.com/SAML/Attributes/Role
# Value: arn:aws:iam::123456789012:role/EngineerRole,arn:aws:iam::123456789012:saml-provider/OktaProvider

# Set maximum session duration (8 hours is reasonable for human access)
aws iam update-role \
  --role-name EngineerRole \
  --max-session-duration 28800

SAML Attack Surface

Attack What It Does Why It Works Prevention
XML Signature Wrapping (XSW) Attacker inserts a malicious assertion, wraps it around the legitimate signed one; some SPs validate the wrong element SAML’s XML structure is complex; naive signature validation checks the signed element, not the element the SP reads Use a vetted SAML library — never hand-roll parsing
Assertion replay Steal a valid assertion (e.g., via network intercept) and replay it before NotOnOrAfter If the SP doesn’t track used assertion IDs, the same assertion can be used multiple times Short expiry; SP tracks seen assertion IDs
Audience bypass SP doesn’t verify the Audience field An assertion issued for SP A can be used at SP B Always validate Audience matches your SP entity ID

XML Signature Wrapping is the most interesting attack historically — it was how security researchers demonstrated SAML implementations in AWS, Google, and others could be bypassed before vendors patched their libraries. The lesson: SAML is complex enough that rolling your own parser is asking for a vulnerability.

OpenID Connect (OIDC) — The Modern Protocol

OIDC is JSON-based, REST-native, and designed for the web and API-first world. Built on top of OAuth 2.0, it’s the protocol behind “Sign in with Google,” GitHub’s OIDC tokens for Actions, and workload identity federation across cloud providers.

Token Anatomy

An OIDC ID Token is a JWT — three base64-encoded parts separated by dots:

Header.Payload.Signature

Header:
{
  "alg": "RS256",           ← signing algorithm
  "kid": "key-id-123"       ← which key signed this (for JWKS rotation)
}

Payload (the claims):
{
  "iss": "https://accounts.google.com",         ← who issued this token
  "sub": "108378629573454321234",               ← stable user identifier (not email)
  "aud": "my-app-client-id",                   ← who this token is for
  "exp": 1749600000,                           ← expires at (Unix timestamp)
  "iat": 1749596400,                           ← issued at
  "email": "[email protected]",
  "email_verified": true,
  "hd": "company.com"                          ← hosted domain (Google Workspace)
}

Signature: RSA-SHA256(base64(header) + "." + base64(payload), idp_private_key)

The relying party (your application, or AWS STS) validates the signature using the IdP’s public keys — available at the JWKS endpoint (/.well-known/jwks.json). The signature verification proves the token was issued by the expected IdP and hasn’t been tampered with since.

The Full OIDC Token Exchange (GitHub Actions → AWS)

# GitHub Actions automatically provides an OIDC token in the runner environment
# The token contains: iss=token.actions.githubusercontent.com, repo, ref, sha, run_id, etc.

# Step 1: Fetch the OIDC token from GitHub's token service
TOKEN=$(curl -H "Authorization: bearer $ACTIONS_ID_TOKEN_REQUEST_TOKEN" \
  "$ACTIONS_ID_TOKEN_REQUEST_URL&audience=sts.amazonaws.com" | jq -r '.value')

# Step 2: Present to AWS STS for exchange
aws sts assume-role-with-web-identity \
  --role-arn arn:aws:iam::123456789012:role/GitHubActionsRole \
  --role-session-name github-deploy \
  --web-identity-token "${TOKEN}"

# STS performs these validations:
# 1. Fetch GitHub's JWKS: https://token.actions.githubusercontent.com/.well-known/jwks
# 2. Verify signature is valid
# 3. Verify iss = "token.actions.githubusercontent.com" (matches OIDC provider)
# 4. Verify aud = "sts.amazonaws.com"
# 5. Verify sub matches the trust policy condition
# 6. Verify exp is in the future

The trust policy condition on the IAM role is what prevents any GitHub repository from assuming this role:

{
  "Version": "2012-10-17",
  "Statement": [{
    "Effect": "Allow",
    "Principal": {
      "Federated": "arn:aws:iam::123456789012:oidc-provider/token.actions.githubusercontent.com"
    },
    "Action": "sts:AssumeRoleWithWebIdentity",
    "Condition": {
      "StringEquals": {
        "token.actions.githubusercontent.com:aud": "sts.amazonaws.com",
        "token.actions.githubusercontent.com:sub": "repo:my-org/my-repo:ref:refs/heads/main"
      }
    }
  }]
}

The sub condition is the security boundary. repo:my-org/my-repo:ref:refs/heads/main means: only runs triggered from the main branch of my-org/my-repo can assume this role. A pull request from a fork, a run from a different repo, or a run from a different branch — all get a different sub claim and the assumption fails.

I’ve reviewed trust policies that omit the sub condition and just check aud. That means any GitHub Actions workflow — in any repository, owned by anyone — can assume that role. That’s not a misconfiguration to be theoretical about: public GitHub repositories exist, and they can trigger GitHub Actions.

OIDC Validation Checklist

Every application that validates OIDC tokens must check all of these:

✓ Signature valid (using IdP's JWKS endpoint — not a hardcoded key)
✓ iss matches the expected IdP URL
✓ aud matches your application's client ID (not just "any audience")
✓ exp is in the future
✓ nbf (not before), if present, is in the past
✓ iat is recent (within your clock skew tolerance)
✓ For workload identity: sub is pinned to the specific workload

Skipping aud validation is the most common mistake. A token issued for application A with aud: app-a-client-id should not be accepted by application B. Without audience validation, any application in your system that can obtain a token for the IdP can reuse it at any other application. Libraries like python-jose and jsonwebtoken validate aud by default — but they need to be configured with the expected audience value.

Enterprise Federation Patterns

Multi-Account AWS with IAM Identity Center + Okta

The pattern I deploy in every multi-account AWS environment:

Okta (IdP)
  └── IAM Identity Center
        ├── Account: prod     → Permission Sets: ReadOnly, DevOps
        ├── Account: staging  → Permission Sets: Developer
        ├── Account: shared   → Permission Sets: NetworkAdmin, SecurityAudit
        └── Account: sandbox  → Permission Sets: Admin (sandbox only)

# Engineers access accounts through Identity Center portal
aws configure sso
# Prompts: SSO start URL, region, account, role

aws sso login --profile prod-readonly

# List available accounts and roles (useful for tooling and scripts)
aws sso list-accounts --access-token "${TOKEN}"
aws sso list-account-roles --access-token "${TOKEN}" --account-id "${ACCOUNT_ID}"

# Get temporary credentials for a specific account/role
aws sso get-role-credentials \
  --account-id "${ACCOUNT_ID}" \
  --role-name ReadOnly \
  --access-token "${TOKEN}"

When an engineer is offboarded from Okta, they lose access to every AWS account immediately. No individual IAM user deletion across 20 accounts. No access key hunting. One action in Okta, complete revocation.

Just-in-Time (JIT) Provisioning

Rather than creating user accounts in every downstream system ahead of time, JIT provisioning creates accounts on first login:

  1. User authenticates to IdP
  2. SAML/OIDC assertion includes group memberships and attributes
  3. SP receives assertion, checks if a user account exists for this sub
  4. If not: create the account with attributes from the assertion
  5. Grant access based on group claims
  6. On subsequent logins: update the account’s attributes if claims changed

The security property: when a user is disabled in the IdP, their account in downstream systems becomes inaccessible even if the account object still exists. There’s nothing to log in with. JIT accounts don’t survive IdP deletion — they’re inactive shells that produce no risk.

The IdP Is the Trust Anchor — Protect It Accordingly

The entire security of a federated system is bounded by the security of the IdP. If an attacker can log into Okta as an admin, they can issue valid SAML assertions for any user, for any role, to any SP that trusts Okta. Every downstream system is compromised simultaneously.

This is not theoretical. In the 2023 Caesars and MGM Resorts attacks, initial access was achieved through social engineering against identity provider support — not through technical exploitation of cloud infrastructure. Once identity infrastructure is compromised, everything downstream follows.

What this means practically:

  • MFA for all IdP admin accounts — hardware FIDO2 keys, not TOTP. TOTP codes can be phished in real-time. Hardware keys cannot.
  • PIM / JIT access for IdP configuration changes — no standing admin access
  • Separate monitoring and alerting for IdP admin activity
  • Audit who can modify SAML/OIDC configurations and attribute mappings in the IdP — these are the levers for privilege escalation
  • Narrow audience restrictions — configure which SPs can receive assertions; don’t create a wildcard IdP configuration that serves all SPs

Conditional Access — Adding Context to Federation

Modern IdPs support Conditional Access policies that restrict when assertions are issued:

// Entra ID Conditional Access: require MFA + compliant device for AWS access
{
  "conditions": {
    "applications": {
      "includeApplications": ["AWS-Application-ID-in-Entra"]
    },
    "users": {
      "includeGroups": ["all-employees"]
    },
    "locations": {
      "excludeLocations": ["NamedLocation-CorporateNetwork"]
    }
  },
  "grantControls": {
    "operator": "AND",
    "builtInControls": ["mfa", "compliantDevice"]
  }
}

This policy: when an employee accesses AWS from outside the corporate network, they must use MFA on a device that MDM has verified as compliant. From inside the network, the policy still applies but the named location exclusion can relax certain requirements.

Conditional Access is how you move beyond “authenticated to IdP” as the only gate. Device health, network location, risk score — these become inputs to the access decision.

Framework Alignment

Framework Reference What It Covers Here
CISSP Domain 5 — Identity and Access Management Federation is the mechanism for extending identity trust across organizational boundaries
CISSP Domain 3 — Security Architecture Trust relationships must be explicitly designed; overly broad federation trust is an architectural failure
ISO 27001:2022 5.19 Information security in supplier relationships Federation with third-party IdPs and SPs establishes a cross-organizational trust boundary that must be governed
ISO 27001:2022 8.5 Secure authentication SAML and OIDC are the secure authentication protocols for federated access — token validation requirements
ISO 27001:2022 5.17 Authentication information Credential lifecycle in federated systems — no passwords distributed to SPs; IdP manages authentication
SOC 2 CC6.1 Federated identity is the access control mechanism for human access to cloud environments in CC6.1
SOC 2 CC6.6 Logical access from outside system boundaries — federation with external IdPs and partner organizations

Key Takeaways

  • Federation means downstream systems trust the IdP’s signed assertion — they never see credentials and don’t need to manage them independently
  • SAML is XML-based, browser-oriented, widely supported for enterprise SSO; OIDC is JWT-based, API-friendly, the protocol for modern workload identity and consumer SSO
  • In OIDC, the sub condition in trust policies is what prevents any workload from assuming any role — omitting it is a critical misconfiguration
  • Validate all JWT claims: signature, iss, aud, exp, sub — libraries do this, but they need correct configuration
  • The IdP is the trust anchor — its security posture bounds the security of every system that trusts it. Treat IdP admin access with the same controls as your most sensitive systems.
  • JIT provisioning and Conditional Access extend federation from “who are you” to “are you in an appropriate context right now”

What’s Next

EP11 brings this into Kubernetes — RBAC, service account tokens, and how the Kubernetes authorization layer interacts with cloud IAM. Two separate systems, both requiring security. A gap in either becomes a gap in both.

Next: Kubernetes RBAC and AWS IAM

Get EP11 in your inbox when it publishes → linuxcent.com/subscribe
